EziLab Desktop Conductivity Meter EZL-DCM124 measures conductivity, resistivity, TDS, and salinity across wide analytical ranges for laboratory conductivity meter workflows. Automatic temperature compensation from 0°C to 100°C maintains measurement stability across varied sample types. High-resolution sensing supports detection of both low and high conductivity samples. Multiple electrode constants accommodate varied water qualities for flexible operation. Desktop form allows stable bench placement for routine laboratory analysis. DC power input supports uninterrupted continuous operation. Suited to biotechnology laboratories, fine chemistry analysis, quality control testing, reverse osmosis monitoring, and distilled water evaluation via Lab Equipment and EziLab's full range of conductivity meters for lab workflow integration.
| Measuring Range |
0.00 to 20.00 µS/cm 20.0 to 200.0 µS/cm 200 to 2000 µS/cm 2.00 to 20.00 mS/cm 20.0 to 200.0 mS/cm 200 to 2000 mS/cm |
|---|---|
| Resistivity | 0 to 100 MΩ.cm |
| TDS | 0 to 100 g/L |
| Salinity | 0 to 100 ppt |
| Resolution | 0.01/0.1/1 µS/cm 0.01/0.1 mS/cm |
| Accuracy |
Electrode: ± 0.5 % FS Instrument: ± 1.00 % FS |
| Temperature Compensation | 0 °C to 100 °C (Automatic) |
| Electrode Constant | 0.1/1/10 cm-1 |
| Temperature Measuring Range | 10 °C to 110 °C |
| Temperature Resolution | 0.1 °C |
| Temperature Accuracy | 5 °C to 60 °C: ± 0.3 °COthers: ± 0.5 °C |
| Ambient Temperature | 5 °C to 35 °C |
| Ambient Humidity | ≤ 80 % |
| Power | DC 12V/1A |
| Dimensions (W×D×H) | 240×170×70 mm |
| Weight | 600 g |
7-inch high resolution capacitive touch screen
Auto-calibration, automatic temperature compensation electrode, data storage, USB port, self-diagnosis functions
Bilingual operation
Data storage of 1000 sets of measurement data and is transferable
Auto-recognition of 8 conductivity standard solutions
Bluetooth module and wireless printer
Optional PC software and cell phone APP
1 point calibration of electrode meet accuracy for 0.5µS/cm – 200mS/cm
Switch between conductivity, TDS, salinity and resistivity
Multinomial calculation of TDS, salinity
Smart judge electrode status for accurate results
Dustproof and waterproof meter meet IP54 Grade
Has a “ready” indicator and HOLD function
It has a wide range of applications, including high precision conductivity measurements in scientific research, quality control, biotechnology, and fine chemistry, such as measuring the conductivity of common water solutions, high purity water, reverse osmosis water, and distilled water.
Desktop Conductivity Meter LO-DCM100 Series 1 pc
Composite Conductivity Electrode 1 pc
Power Adapter 1 pc
Electrode Holder and Base 1 set
Instruction Manual in USB 1 copy
